IYSC06 - The Ultimate Operative Protocol to Accomplish CO2-EVAR: Results from an Interventional Multicentric Study

Objectives: CO2-angiography in endovascular aortic repair (CO2-EVAR) has been proposed for treatment of AAA especially in patients with chronic kidney disease and/or allergy to iodinated contrast medium (ICM). Issues regarding the standardization of the technique, such as visualization of the lowest renal artery (LoRA) and the best quality image in angiographies performed from pigtail or introducer-sheath, are still unsolved.
Aim of the study was to analyze different steps of CO2-EVAR, in order to create an operative protocol to standardize the procedure.

Methods: Patients undergoing CO2-EVAR were prospectively enrolled in 5 European centers from 2018 to 2021. CO2-EVAR was performed using an automated injector (Pressure:600mmHg; Volume:100cc); a small amount of ICM was injected in case of difficulty in LoRA visualization or other doubts. LoRA visualization and image quality (1=low, 2=sufficient, 3=good, 4=excellent) were analyzed and compared at different procedure steps: preoperative CO2-angiography from Pigtail and femoral Introducer-sheath (1stStep), angiographies from Pigtail at 0%, 50% and 100% of main body deployment (2ndStep), contralateral hypogastric artery (CHA) visualization with CO2 injection from femoral Introducer-sheath (3rdStep) and completion angiogram from Pigtail and femoral Introducer-sheath (4thStep). Intraoperative and postoperative CO2-related adverse events were also evaluated. Chi-squared and Wilcoxon were used for statistical analysis.

Results: In the considered period, 65 patients undergoing CO2-EVAR were enrolled, 55/65(84.5%) male with a median age of 75(11.5) years. The median ICM was 20(54)cc; 19/65(29.2%) procedures were performed with 0cc ICM. In the 1st Step the median image quality was significantly higher with CO2 injected from the femoral introducer [Pigtail 2(3)vs.3(3) Introducer, p=.008]. In the 2nd Step LoRA was more frequently detected at 50% (93%vs.73.2%,p=.002) and 100% (94.1%vs.78.4%,p=.01) of main body deployment compared with first angiography from Pigtail; similarly, image quality was significantly higher at 50% [3(3)vs.2(3),p= <.001] and 100% [4(3)vs.2(3),p=.001] of main body deployment. CHA was detected in 93% cases (3rdStep). The mean image quality was significantly higher when final angiogram (4thStep) was performed from introducer (Pigtail 2.6±1.1vs.3.1±0.9 Introducer, p= <.001). The rates of intra- and postoperative adverse events (pain, vomit, diarrhea), all transient and clinically mild, were 7.7% and 12.5% respectively.

Conclusions: Preimplant CO2-angiography should be performed from femoral Introducer-sheath. Main body steric bulk during its deployment should be used to improve image quality and LoRA visualization with CO2. CHA can be satisfactorily visualized with CO2. Completion CO2-angiogram should be performed from femoral Introducer-sheath. This operative protocol allows to perform CO2-EVAR with 0cc or minimal ICM, with a low rate of mild transient perioperative complications.
